Parameter:
Turbine Model: FD2.8-1.0
Rated Power (W): 1000
Rated Voltage (V): DC56
Started-up Wind Speed (m/s): 2.4
Rated Wind Speed (m/s): 9
Security Wind Speed (m/s): 35
Working Wind Speed (m/s): 2.8~20
Working Temperature (degree celsius): -20 -- +60
Rotor Diameter (m): 2.8
Blade Material* Qty: Reinforced Fiber Glass *3PCS
Blade Made Artwork: RTM+Vacuum Assisted
Generator Style: 3-Phase Synchronous AC
Outer Frame Material: Aluminum Alloy+ Casted Iron
Speed Control: Electromagnetic Brake+ Mechanical Yawing+ Ratio stall
Protection under Big Winds: Electromagnetic Brake
Net Weight (KG): 75
Model: FKJ56-1
Off grid controller (PWM): NB1/48-220/110
Matched Guyed Pole: 12V150Ah*4PCS
Matched mono-standing Pole: 9m/ 76*4mm
Matched Battery Group: 10m/ 140-260*5mm
Blade Model: YA1K
Blade Length: 1.34m
Rotor Diameter: 2.8m
Matched Power: 1KW
Started-up Wind Speed: 2.4m/s
Rated Wind Speed: 9m/s
Security Wind Speed: 40m/s
Rated Rotation: 500r/min
Blade size: 1.34m*0.24m*0.18m
Single Blade W: 2.34Kg
Artwork: Hand Lay-up
Material: Reinforced Fiber Glass
Controller NW(kg): 6.5
Controller GW(kg): 8
Controller out packing size(m): 0.45*0.4*0.21
Inverter GW(kg): 21.5
Inverter net size(m): 0.465*0.34*0.245
Certification: CE, RoHS, ISO9001: 2000
Product Features:
1. Low starting wind speed, high efficiency wind power; Small volume, Graceful
Sharp, low noise.
2. Installation using humanized
Shenzhen Effsun Wind Power Co., Ltd. is a company specialized on medium & small wind turbine generator group and relevant parts development, manufacturing and selling.
We pay high attention on science development. We own professional persons and research equipments on aerodynamics analyse, mechanical design, generator design&manufacturing, also electrical regulate. Based on wind turbine whole set basic theory, every model go from science aerodynamics calculate, intensity analyse, electromagnetic calculate, efficiency study, jarring analyse and matching analyse, all have detailed design, test and produce plan. The wind turbine passed wind tunnel test. Whole system function and various working conditions all have detailed test reports.
Professionally organized and managed, we spare no effort in ensuring the supply of high quality various wind turbine and guarantee 100% service satisfaction for national & overseas consumers. Accordingly, all of our products conform to CE and ISO9001 quality standards.
We engaged in wind turbine generator development and application, we launched 300W, 500W, 1kw small wind turbine in 2000. When time goes by, our technology and products gradually matured, we launched 2kw, 3kw, 5kw, 10kw, 20kw wind generator.
Therefore, if you or your company are interested in any of our products, please don't hesitate to contact us for more details. We look forward to supplying you with our high quality products in the near future.
