| Price: | Negotiable/Piece |
|---|---|
| Trade Terms: | FOB |
| Min Order: | 1/Set |
| Pay Type: | L/C,T/T,Paypal,Western Union |
| Off grid solar power supply system- SP-1KW | |||
|
System Basic Information |
Solar panel rated output power: 1KW Suitable for daily power consumption: < 3200WH Allowable max loads power: 3KW |
||
| Solar panel |
type: polycrystalline or mono solar panel Max power: 160w Vmp: 43.2V Imp 2.22A Size: 636*557*35mm 25 years power output guarantee (CE TUV) |
QTY 6pcs |
|
| PV Array Combiner |
Simplify wiring between PV array and controller, protections to controller Wide range of DC input voltage Reliable thunderstorm& surge protection Multiple PV strings inputs Service time: 10 years, |
QTY 1pc |
Notes: 1. pictures show are for reference. 2. power output data is based on areas with daily average peak power shine of 4.5hrs 3. the battery capacity is designed for power storage of 1.5-2 days PV output 4. solar panel rack can be specially designed based on site condition Remark: 1)solar panel have 3 years warranty; 2)other parts have 2 years warranty; 3)ship the free parts for service(best service in china) 4)accept OEM |
| Hybrid solar Inverter |
Solar inverter with controller built it Inverter power: 1kw/48v controller: 40A LCD display inverter and controller info With AC charger built in Protection against short-circuit, over load, high-voltage and low-voltage protection |
QTY 1pc |
|
| Battery |
Capacity: 12V/200AH Solar power lead-acid battery, full sealed Service life: 5-6 years, |
QTY 4pcs |
|
| Solar panel rack |
Flat – roof type mounting rack, No welding/ cutting at site, easy mounting. More options to select: Slope-roof mounting rack Array type rack; Standing – pole type rack |
QTY 1set |
|
| Cables |
International standard, with specification suitable for solar system, |
100m |
|
| Off grid solar power supply system- SP-2KW | |||
|
System Basic Information |
Solar panel rated output power: 2KW Suitable for daily power consumption: < 6500WH Allowable max loads power: 5KW |
||
| Solar panel |
type: polycrystalline or mono solar panel Max power: 200w Vmp: 36.8V Imp 8.3A Size: 1498*998*40mm 25 years power output guarantee (CE TUV) |
QTY 10pcs |
|
| PV Array Combiner |
Simplify wiring between PV array and controller, protect for controller Wide range of DC input voltage Reliable thunderstorm& surge protection Multiple PV strings inputs Service time: 10 years |
QTY 1PC |
Notes: 1. pictures show are for reference. 2. power output data is based on areas with daily average peak power shine of 4.5hrs 3. the battery capacity is designed for power storage of 1.5-2 days PV output 4. solar panel rack can be specially designed based on site condition Remark: 1)solar panel have 3 years warranty; 2)other parts have 2 years warranty; 3)ship the free parts for service(best service in china) 4)accept OEM |
| Hybrid solar Inverter |
Inverter power: 2kw/48v Controller model: 48v/30A LCD display inverter and controller info With AC charger built in Protection against short-circuit, over load, high-voltage and low-voltage protection |
QTY 1PC |
|
| Battery |
12V/150AH per piece Solar power lead-acid battery, full sealed Service life: 5-6 years |
QTY 10pcs |
|
| Solar panel rack |
Flat – roof type mounting rack, No welding/ cutting at site, easy mounting. More options to select: Slope-roof mounting rack Array type rack; Standing – pole type rack |
QTY 1set |
|
| Cables | International standard, with specification suitable for solar system | 100m | |
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
|---|---|
| Product Name: | Solar Power Home System Model |
| Off Grid System Parts: | Solar Panle+Hybird Inverter+Battery |
| Delivery Time: | 5-7 Days |
| Solar Panel Warranty: | 3 Years |
| Other Parts Warranty: | 2 Years |
| Shipment: | Ship by Sea Suggest |
| Payment: | T/T in Advantace |
| Certitication: | Solar Panel Have CE |
| Servcie: | Ship The Free Parts |
| Promise: | Best Quality and After Sales Servcie |
