| Price: | US $ 0.85/Piece |
|---|---|
| Trade Terms: | FOB,CFR,CIF |
| Min Order: | 1/Piece |
| Pay Type: | L/C,T/T,D/P,Paypal,Money Gram |
| Off grid solar power supply system- SP-2KW | |||
| System Basic Information | Solar panel rated output power: 2KW Suitable for daily power consumption: 6500WH Allowable max loads power: 5KW | ||
| Solar panel | type: polycrystalline or mono solar panel Max power: 200w Vmp: 36.8V Imp 8.3A Size: 1498*998*40mm 25 years power output guarantee (CE TUV) | QTY 10pcs | |
| PV Array Combiner | Simplify wiring between PV array and controller, protect for controller Wide range of DC input voltage Reliable thunderstorm& surge protection Multiple PV strings inputs Service time: 10 years | QTY 1PC | Notes: 1. pictures show are for reference. 2. power output data is based on areas with daily average peak power shine of 4.5hrs 3. the battery capacity is designed for power storage of 1.5-2 days PV output 4. solar panel rack can be specially designed based on site condition Remark: 1)solar panel have 3 years warranty; 2)other parts have 2 years warranty; 3)ship the free parts for service(best service in china) 4)accept OEM |
| Hybrid solar Inverter | Inverter power: 2kw/48v Controller model: 48v/30A LCD display inverter and controller info With AC charger built in | QTY 1PC | |
| Battery | 12V/150AH per piece Solar power lead-acid battery, full sealed Service life: 5-6 years | QTY 10pcs | |
| Solar panel rack | Flat – roof type mounting rack, No welding/ cutting at site, easy mounting. More options to select: Slope-roof mounting rack Array type rack; Standing – pole type rack | QTY 1set | |
| Cables | International standard, with specification suitable for solar system | 100m | |
| Prod Model: | SP2kw 3KW |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Solar Panel Efficiency: | 17% |
| Solar System: | 1kw 5kw |
| Open Circuit Voltage: | 21.8V-44.2 |
| Max Power Voltage: | 17.2-15.2 |
| Operating Current: | 2.22-4-96 |
| Max. System Voltage: | 1000V |
| Dimension(L*W*H): | 636*557*35mm |
| Area: | 0.35-1.3 |
| Working Way: | Home Use |
| Solar Panel Power: | 180W-200W |
| System: | Off-Grid system |
