The GPM180 series panels consists of 72PCS 125*125mm mono-crystalline silicon solar cells which are in high efficiency, individually characterized and electronically matched before interconnection. Laminated with high quality toughened glass, EVA, andTPT, the operating characteristcs of solar cells can be ensured under any climate conditions.
After assembled by anodized aluminum alloy frame and MC type junction box, cable with connector, the Guofei solar modules are designed for long service life, easy to install, withstand the storm, high wind and hail impact etc.
Module: GPM180-B-72
Encapsulation: Glass/EVA/Cells/EVA/TPT
Size&number: 125*125mm 72/6*12 PCS
Maximum Power(pmax): W 180 185 190
Tolerance 3%
Open Circuit Voltage(voc): V 44.8 44.8 44.8
Short Circuit Current(isc): A 5.48 5.51 5.62
Maximum Power Voltage(vmp): V 36.0 36.2 36.4
Maximum Power Current(imp): A 5.00 5.11 5.20
Max. Syst. Oper. Voltage: V 1000V
Diodes: 3by -pass
Dimension: Mm 1580*808*50
Weight: Kg 16
Operate temp. Scope: 0 C -40/ +85
Relative humidity: 0 to 100%
Resistances: 227g steel ball fall down from 1m height and 60m/s wind
Warranty: Pm is not less than 90% in 10 years and 80% in 25 years.
Jiangsu Green Power PV Co., Ltd (GPPV). Is a high-tech enterprise specialized in the R&D, production, marketing and serving of solar cells, solar modules as well as photovoltaic generation systems. In 2008, the enterprise started to sell solar modules and in 2009, it put four international advanced solar cell production line into operation.
The company strictly implements ISO9000 international management system and its solar module products have been certified to CE, TUV, IEC, VDE and the other international authoritative certification. The company always adheres to customer needs. With good-quality product and service, GPPV makes a good brand effect in the international market and its product obtains good reputation in South-East Asia and in European countries such as Germany, Spain and Italy etc.
Our products are widely used in communications, industrial, transportation, marine, lighting and a variety of large-scale solar photovoltaic grid-connected and independent generation system.
