| Price: | US $ 11188/Piece |
|---|---|
| Trade Terms: | FOB,CFR,CIF |
| Min Order: | 1/Piece |
| Pay Type: | L/C,T/T,Western Union |
Prime power | 150kw |
Standby power | 165kw |
Rated speed | 1800 rpm |
Output frequency | 60 hz |
Phase | 3 |
Rated voltage | 400 v |
Noise db(a) @7m | 100 |
Engine model | Wd615 64d-15 |
Alternator model | Mp-150-4 |
Engine model | Wd615 64d-15 |
Configuration | 4 cycle,6 cylinders in line |
Aspiration | Turbocharged |
Bore×stroke | 126x130 |
Rated speed | 1800rpm |
Displacement | 9.726l |
Prime power | 160kw |
Speed governor | Electrical |
Cooling system | Water-cooled , 40°c radiator as standard, 50°c is optional. |
Speed stability (%) | ≤5% |
Fuel consumption at 100% load | 208 |
Starter motor | Dc24v, |
Alternator model | Mp-150-4 |
Alternator manufacturer | Marathon |
Exciter type | Single bearing, brushless, self-excited |
Rated output prime power | 150kw |
Rated speed | 1800 rpm |
Rated frequency | 60 hz |
Phase | 3 |
Rated voltage | 440 v(available with customer requirements) |
Power factor | 0.8 |
Voltage adjust range | ≥5% |
Voltage regulation nl-fl | ≤±1% |
Insulation grade | H |
Protection grade | Ip23 |
| Prod Model: | HQ150GF |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Rated Power: | 150kw/187.5kVA |
| Certificates Of Engine: | GB/T2820-97,ISO8528, ISO9001 |
| Warranty: | 18months |
| Rated Voltage: | 220,110,230,240,380,400,440,415V |
| Optional: | Silent/ATS/Trailer |
| Starting Method: | Key Starting |
| Dimension: | 2450*800*1600mm |
| Color: | as Your Requset |
| Stroke: | Six Stroke |
| Type: | Basic Diesel Generator |
| Cooling Method: | Water Cooling |
| Installation Method: | Portable |
| Output Type: | AC Single Phase |
