150kVA Generator Diesel Type with Cummins Engine

150kVA Generator Diesel Type with Cummins Engine
Price: US $ 11900/Piece
Trade Terms: FOB,CFR,EXW
Min Order: 1/Piece
Pay Type: L/C,T/T


Product Description

1.International Warranty Service
2. Short delivery time
3. With ISO9001& CE certification
4. Spare parts are easy to get from worldwide market with much cheaper price
5. Coupled with Stamford alternator or Chinese alternator
6. Perfect after-service network
7. Both 50Hz and 60Hz

Model No.STANDBY POWERPRIME POWERENGINEALTERNATORCONTROLLER
KVAKWKVAKW
OCL-1501501201401126BTAA5.9-G2LTG274FA16110
230/400VAC,50Hz,0.8PF (lag),Three phase four wires

Generator set specifications
Governor ClassISO8528 G3
Potential Drop1%
Steady Voltage Regulation1%
Frequency DropSynchronous(0%)
Steady-state Frequency0.25%
R.R.I.SuppressionBS EN 61000-6-4 / BS EN 61000-6-2
Fuel Consumption Rate ,g/kw.h(L/hr)220(30)
Starting Battery Capacity ,A/hrhhr120*2
Total Coolant Capacity ,L29
Fuel Capacity (base tank),LN/A
Engine Data
Model6BTA5.9-G2
TypeIn-line 6 Cylinder,4 Cycle
Displacement ,L5.9
Compression Ration16.5:1
AspirationTurbo, Air / Air Cooling
Fuel SystemPN type Fuel Pump,EFC Electronic Governor
Bore*Stroke(mm)102*120
Rated Speed ,rpm1500
Governor TypeElectronic
Starting Voltage24V ,Negative ground
Battery Charging System24V 35A
Lubricant Capacity ,L16.4
Coolant Capacity, L29
Alternator Data
Protection ClassIP21
Insulation ClassClass H
Temperature Rise in Standard125 ºC(When Ambient Temp.is 40 ºC)
Excitation TypeBrushless & Self-excited
Waveform DistortionNo load<1.5% Non-Distorting balanced linear load<5%
Telephone Interference(TIF)<50
Telephone Interference(THF)<2%
Exhaust System
Exhaust air flow19.44m3/min
Exhaust Temperature  495ºC
Max Back Pressure 10kPa
Air Intake System
Max Intake Restriction6.35kPa
Burning Capacity8.7m3/min
Air Flow190m3/min
Lubricant System
Total Lubricant Capacity16.4L
Lubricant Consumption4g/kwh
Engine Oil Tank Capacity14.2L
Oil Pressure at Rated Speed345kPa


FAQ(Frequently Asked Question):

1.     What is your warranty period?
Our payment terms is 1 year or 1000 running hours whichever comes first. But based on some special project, we can extended our warranty period.

2.     Does your generator have global warranty?
Yes, most of our products like Cummins diesel generator enjoy the global warranty service. And the alternator we use like Leateck also enjoy the global warranty service, so you do not need to worry about the aftersales service.

3.     Can you accept OEM?
Yes, we can accept OEM.

4.     What is your payment  terms?
We can accept T/T 30% in advance, and the balance 70% shall be paid before shipment or L/C at sight.

5.     What is your delivery time?
Our normal delivery time is 20 to 25 days. But if your order is some special engine and alternator, then the delivery time is longer.


Contact Details:
FOSHAN ORIPO POWER ENGINEERING CO.,LTD
Contact person:Janet
Mobile:+8618923200408
Fax:0757-28791208
Web:en.oripo.com
Prod Model: OCL-150
Markets: South America,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia
Dimension: 3700*1300*1887mm
Type: Micro-Computer Control Automatic Diesel Generator
Installation Method: Fixed
Stroke: Four Stroke
Cooling Method: Water Cooling
Output Type: AC Three Phase
Oripo Established in 1998, Oripo Power Engineering Co., Ltd is professional leading manufacturer, suppliers, exporter and authorized dealers of diesel gensets. With over 20, 000 square meters and a staff nearly 200, the headqauter is loacted in Foshan city, adjacent to Guangzhou which is the trade center of Guandong province. We offering power genset, industrial genset, silent genset, weather proof genset, Cummins genset, Perkins genset, Yuchai genset, Shanghai Dongfeng genset, Deutz genset, Weichai electric genset, China domestic genset, silent diesel generator, portable power generator, trailer diesel generator and electric power generator.

Currently, Oripo cooperated with multinational companies formed a strategic partnership. Import CUMMINS, PERKINS series generator sets, and purchase engine from with Cummins, SDEC, Yuchai, LOVOL, Deutz, alternater with STAMFORD, MARATHON, LEADTECH and other international or domestic famous brand. Establish a long-term friendly cooperation relations with the branded engine and alternator company, authorized to be the OEM partner, In 2009, Oripoe authorized by Cummins, Shanghai Dongfeng and Yuchai to provide OEM service. As professional qualified manufacturer provide OEM genset, spare parts, after sale service, in order to better serve customers and laid a solid foundation.

During the last ten odd years, Oripo has been dedicated to pursuing professional production, thus prevailing in the market with its superior quality, cutting-edge technology and tailor-made services. Moreover, with an endeavor to expand our business operations, we adhere to ethical business practices, transparent business dealings and work to attain the confidence and trust of our clients.
