High pressure oxygen generator(JAY-15)
Oxygen Outlet Pressure (0.14-0.4Mpa)
Detailed Information of JAY-15 Oxygen Concentrator with High Outlet Pressure (0.14-0.4Mpa)
Application
1. Central oxygen supply system of small hospital. One set of oxygen concentration machine is able to supply oxygen for 5-7 patents.
2. Connecting to ventilator or anesthesia machine in operating theater and ICU
3. Industrial use such as welding, glass cutting, etc
4. Fish farming
5. Veterinary use
Technical Parameters
ModelJAY-15
Oxygen flow0-15L/min
Outlet pressure (Mpa)0.14-0.4
Oxygen concentration93%± 3%
Noise level (dB)≤ 60
PowerAC220V (± 22V), 50Hz (± 1Hz); AC230V, 50Hz
Optional: AC220V/110V (± 10%), 50/60Hz (± 1Hz)
Power consumption1500/1550
LCD displayStarting times, operating pressure, present working time, accumulated working time, preset time from 10mins to 40hours
AlarmPower failure alarm; High/low pressure alarm
DehumidifierAutomatic dehumidifier/Refrigerated air dryer
Net weight (kg)85/118
Size (mm)920× 360× 660860× 580× 660
Longfian Scitech Co., Ltd, located in Longxing Building A(413), 77 Longxing Road, 071051 Baoding China, The company has first-class professional management personnel and research&development technical team, with their own product development capabilities, mainly engaged in medical molecular sieve oxygen concentrator as well as assorting the development of electronic products, now has a variety of standard models and a variety of uses oxygen concentrator, has successfully developed JAY-1, JAY-2, JAY-3, JAY-5, JAY-6, JAY-8, JAY-10 type normal pressure medical oxygen concentrator, JAY-10-4.0, JAY-15-4.0, JAY-20-3.5 with 0.14 ~ 4KG pressure of high-pressure oxygen concentrator, industrial oxygen concentrator and ozone generator etc.; The product has got EU's CE certificate, ISO certificate and FDA certificate, and exported to the United States, France, Spain, Germany, Russia, India, Singapore, Turkey, Thailand etc. More than 60 countries and regions, enjoy a high reputation in Foreign markets
In recent years, the company has joined OEM companies and developed some related medical products for the demands of market, especially for pulse oximeter, SpO2&Blood pressure monitor, SpO2&ECG monitor, syringe pump, infusion pump, etc.
Our goal is "PROFESSIONAL IN QUALITY, FOCUS ON RESPIRATORY PRODUCTS ", to meet the demands of various specialists of medical field and continue to bring you not just the innovative equipment but also the most reliable, long-lasting & quality products.
