| Unit Type | Alternator |
| Part Type | UNIT |
| Voltage | 12 |
| Rotation | CW |
| Amperage | 130 |
| Pulley Class | S6 |
| Regulator | IR |
| Fan Type | IF |
| Manufacturer | DENSO |
| Brief | LEXUS RX300 2001-03
6-GROOVE PULLEY 56mm OD
SEARCH: 495449 (ANOTHER VERSION) |
| Detailed | This is a New Style Denso Hairpin Stator Alternator with a Full Black Rear Cover an Oval S-IG-L Plug and a 6-Groove Pulley. This Unit Mounts Much Like the 13844 Used Earlier as well as the 13558 (Others) Used on Many Other Lexus and Toyota Models. |
| MFG# | MFG NAME |
|---|
| AND0382 | ARROWHEAD |
| AND0380 | ARROWHEAD (OLD) |
| 13905 | LESTER |
| 290-5080 | PIC |
| 13905 | BBB |
| 13905 | BBB NEW |
| 186-1056 | BECK ARNLEY |
| 104210-3120 | DENSO |
| 104210-3121 | DENSO |
| 104210-3122 | DENSO |
| 210-0509 | DENSO FIRST TIME FIT |
| A-8960 | DIXIE |
| 10635 | EXCEL |
| Denso Hairpin | FAMILY |
| 13905 | MPA |
| 213-9484 | NAPA POWER PREMIUM PLUS |
| 27060-20190 | TOYOTA |
| A2905 | USA INDUSTRIES |
| 1-2939-01ND | WAI |
| 13905R | WAI |
| 90-29-5543 | WILSON |
| 90-29-5543 | WILSON NEW |
| 12292 | WORLDWIDE |
| MAKE | TYPE | MODEL | YEAR | ENGINE |
|---|
| LEXUS | Auto and Light Truck | RX300 | 2001 | 3.0L |
| LEXUS | Auto and Light Truck | RX300 | 2002 | 3.0L |
| LEXUS | Auto and Light Truck | RX300 | 2003 | 3.0L |
| AEP Number | AEP (OEM) | PART TYPE |
|---|
| BRG0005 | ND949100-2250 | BEARING |
| BRG0014 | ND949100-2790 | BEARING |
| AND7501 | ND021660-0390 | BRUSH |
| AND1307 | ND021620-3001 | BRUSH HOLDER |
| AND1035 | | COVER - RECTIFIER |
| | | COVER - RECTIFIER |
| IHW2612 | ND021506-0070 | DUST SHIELD - SRE BRG |
| AND1628 | | INSULATOR - B+ TERMINAL |
| | | PLUG CODE |
| AND6155 | ND126600-0023 | REGULATOR |
| | ND021200-8160 | ROTOR |
| AND3501 | | SLIP RING |
| AND4030 | ND021100-4940 | STATOR |
| | | TEST LEAD |
| HDW1326 | | THRU BOLT |
