| Unit Type | Starter |
| Part Type | UNIT |
| Voltage | 12 |
| Rotation | CW |
| Teeth | 9 |
| KW | 1.2 |
| Manufacturer | DENSO |
| Starter Type | OSGR |
| Brief | TOYOTA COROLLA 1998-02
ADDL INFO: RIGHT MOUNTING EAR IS THREADED
SEARCH: 484952 (1.4kw VERSION) |
| Detailed | This is the 1.2kw Version of the 1.4kw17727 Used on Toyota Corolla. |
| SND0480 | ARROWHEAD |
| 17737 | LESTER |
| 190-412 | PIC |
| 610-17737 | BARSANCO |
| 17737 | BBB |
| 19631 | BBB (OLD) |
| 17737 | BBB NEW |
| N17727 | BBB NEW |
| N17737 | BBB NEW (OLD) |
| 187-0716 | BECK ARNLEY |
| 228000-6310 | DENSO |
| 228000-6313 | DENSO |
| 280-0270 | DENSO FIRST TIME FIT |
| S-8738 | DIXIE |
| 17737N | EMS |
| 21249 | EXCEL |
| 410-52149 | J & N |
| 57-2816 | MINNPAR |
| 17737 | MPA |
| 44-6773 | NAPA |
| 4N-6773 | NAPA POWER NEW |
| 244-6773 | NAPA POWER PREMIUM PLUS |
| 44-6773 | NAPA POWER SUPREME |
| STR-8102 | NSA |
| 28100-0D010 | TOYOTA |
| S2727 | USA INDUSTRIES |
| 2-1944-ND | WAI |
| 91-29-5480 | WILSON |
| 91-29-5460N | WILSON NEW |
| 91-29-5480 | WILSON NEW |
| 17615 | WORLDWIDE |
| TOYOTA | Auto and Light Truck | COROLLA | 1998 | 1.8L |
| TOYOTA | Auto and Light Truck | COROLLA | 1999 | 1.8L |
| TOYOTA | Auto and Light Truck | COROLLA | 2000 | 1.8L |
| TOYOTA | Auto and Light Truck | COROLLA | 2001 | 1.8L |
| TOYOTA | Auto and Light Truck | COROLLA | 2002 | 1.8L |
| SND3034 | ND028200-6260 | ARMATURE - STARTER |
| BRG0006 | ND949100-5240 | BEARING - ROLLER |
| BRG0016 | 35-4000E | BEARING - ROLLER |
| BRG0008 | ND949100-5250 | BEARING - ROLLER |
| SND6613 | | BOOT - STR. MOTOR TERMINAL |
| SND7520 | | BRUSH (GRD) |
| SND7526 | | BRUSH (POS) |
| SND7528 | | BRUSH (POS) |
| SND1312 | ND028510-5360 | BRUSH HOLDER - STARTER |
| | | BUSHING |
| SND6533 | | CONTACT DISK |
| SND4611 | ND028062-5790 | DRAIN TUBE |
| | | DRAIN TUBE |
| SND5048 | ZN0818 | DRIVE ASSY. |
| | ND028371-6620 | GEAR - INTERMEDIATE |
| IHW6204 | | INSULATOR - STR. B+ STUD |
| IHW6206 | | INSULATOR - STR. B+ STUD |
| IHW6212 | | INSULATOR - STR. B+ STUD |
| SND9206 | | O-RING - STARTER |
| SND6528 | | PLUNGER RETURN SPRING |
| | ND949072-0791 | RETAINING RING - DRIVE |
| SND6034 | | SOLENOID COIL |
| SND6535 | ND053513-7120 | SOLENOID CONTACT |
| SND6531 | ND053513-0241 | SOLENOID CONTACT |
| | ND028099-7220 | SOLENOID CONTACT KIT - MOTOR |
| SND6546 | | SOLENOID CONTACT SET |
| | ND053404-7061 | SOLENOID GASKET |
| SND2601 | | STEEL BALL |
| | | STOP COLLAR - DRIVE |
