12kw Movable Light Tower Diesel Generator Powered by Ricardo Y480DB (HLD-12KW)
Price: |
US $ 1/Piece |
Trade Terms: |
FOB |
Min Order: |
1/Piece |
Pay Type: |
T/T |
Specifications:
Maximum extension of mast: 9m
Elevation: Hydraulic
Raising/lowing mast: Hydraulic
Stages: 3
Turning angle: 360° Non-continuous
Lamp:
Total power of lamps: 4 x 1, 000W
Type of lamps: Metal halide lamp
Light capacity: 4 x 110, 000lm (luminous flux)
Frequency: 50Hz
Lifespan: 5, 000 hours
Working temperature: ≤ 85° C
Connection protection index: IP54
Light coverage: 5 to 7 acres
Generator:
Rated power: 12kW
Standby power: 15kW
Voltage: 120, 220, 230 and 240V
Engine model: Ricardo Y480dB
Engine speed: 1, 500rpm
Engine type: 3 cylinders, in line, water-cooled
Engine aspiration: Natural
Alternator: 4-pole, brush-less
Fuel tank capacity: 100L
Prime fuel consumption at 100% load: 2.0L/hour
Working hours: 50 hours
Emission level: The EU stage IIIA
Control system: RL 210 digital controller
Power outlet: 2
Dimensions: 4, 400 x 1, 200 x 1, 930mm
Net weight: 870kg
Trailer:
Tow hitch: Ring or ball hitch
Stabilizer supports: 5 x manual
Tire size: 52cm
Anti-wind capacity: ≤ 10
Other options:
6m mast
Truck tire: 65cm
6 x 1, 000 metal halide lamps
Prod Model: |
HLD-12KW |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Output Type: |
AC Three Phase |
Cooling Method: |
Water Cooling |
Stroke: |
Four Stroke |
Installation Method: |
Portable |
Type: |
Self-Starting Diesel Generator |
Fuan hengli Machinery Electrical Co., Ltd lies in a beautiful city called Fu'an in Fujian province. Fu'an is known as the Chinese motor city, with 25 million yuan registered capital, the company integrates the electric generating sets and related equipment research and development, manufacturing, marketing and service as a whole. It has rich experience. A large number of industry experts and professional technical talents get together to give you a perfect service. The company has passed the ISO9001 quality management system certification, CE certification, the Sino German authentication and some other qualification certifications at home and abroad, and it also has obtained many domestic and foreign well-known power authorized agents. It has been OEM authorized.
The company mainly produces Common type, automation type, Multi-motor grid type, low noise type, mobile power station type, unmanned type, as well as remote concentrated microcomputer monitoring type, with all sorts of power, from 5KW to 2000KW.
