Diesel generator set (GF-12kVA)
1. Diff engines for your choice, such as Cummins, Perkins, Deutz and other Chinese brand engine weichai and so on.
2. Open frame or silent for your choice. Diff silent canopy for your choice, normal old canopy, new canopy, hiearns newest canopy, especially super silent canopy, 60-65dB at 7 meters.
3. We are factory, have our design and produce workshop and production line, greatly save expense for you.
4. CE, GS, EPA, RoHS, ISO, SONCAP and so on certificates.
|
|
GF-12KVA |
|
Standby Power |
11 KW / 13.75KVA |
|
Prime Power |
10KW / 12KVA |
|
Engine Data |
Model |
LL480BD |
|
Type |
Direct line, Water-cooled, Four stroke, Direct Injection |
|
Cylinder Number |
4 |
|
Bore× Stroke(mm) |
80× 90 |
|
Compression Ratio |
18: 1 |
|
Rated RPM(r/min) |
1500 |
|
Rated Speed Regulation % |
≤ 5 |
|
Maximum No load Speed(r/min) |
≤ 1575 |
|
Minimum No load Speed(r/min) |
≤ 850 |
|
Fuel Consumption(g/kW@ h) |
≤ 238 |
|
Piston Total Displacement(L) |
1.809 |
|
Injection Pressure(MPa) |
20 |
|
Exhaust Temperature(º C) |
≤ 650 |
|
Oil Pressure(kPa) |
300~450 |
|
Oil Temperature(º C) |
85~95 |
|
Cooling Water Temperature(º C) |
75~85 |
|
Fuel Supply Advance Angle(Top Center ° CA) |
15± 1 |
|
Direction of Rotation (face flywheel end) |
Counter-Clockwise |
|
Intake Valve Space (Cold State) mm |
0.20~0.30 |
|
Exhaust Valve Space (Cold State) mm |
0.25~0.35 |
|
Lubricating System |
Pressure, Split, Complex |
|
Start Method |
Electric Start |
|
Alternator Data |
Voltage (V) |
380/220 |
|
Frequency (HZ) |
50 |
|
Insulation Class |
S |
|
Rated Current (A) |
19 |
|
Phase |
3 |
|
Altitude |
≤ 1000m |
|
Power Factor |
0.8 |
|
Voltage Regulation, Stead State |
≤ ± 1% |
|
Connecting Type |
3 Phase and 4 Wires, " Y" type connecting |
|
AVR |
SX460 |
|
Environment Temperature (° c) |
40 |
|
Exciter Type |
Brushless, self-exciting |
|
Protection Grade |
IP23 |
|
Dimension |
Open Type' s Dimension Length × Width × Height (mm) |
1400× 750× 980 |
|
Silent Type' s Dimension Length × Width × Height (mm) |
1650× 850× 1080 |
|
Open Type' s Net Weight(Kg) |
570 |
|
Silent Type' s Net Weight(Kg) |
620 |
|
Open Type' s 20FT Loading Quantity |
24PCS |
|
Silent Type' s 20FT Loading Quantity |
12PCS |
Changzhou Hi-earns Mechanical & Electrical Co., Ltd is established in 2005, which is a high-tech(mechanical&electrical) enterprise, gather "development, production, sales and systematic after-sales services" in one. Our company is certified by ISO9001-2008 QMS, get the EPA approval from U. S. A, CE approval from the European Union, GS approval from Germany and RoHS approval. Our company is one of the most influential enterprise in Eastern China, which is in the field of internal combustion engine.
Our company actively introduce advanced foreign technology and scientific management experience. The company have more than 300 staff, 50 of whom are junior and senior technicists, have 6 advanced automatic production lines. In addition, our company adhere to the brand strategy and international strategy, this greatly improved core competitiveness of us. Our main business includes: Water-cooled diesel generator set, air-cooled diesel engine and generator set, gasoline engine and generator set, water pump, minor agriculture machinery and road machinery equipment. Our company have developed out HR170FB which is turbine type air-cooled diesel engine with the own property right. What's more, this product have gained many certification of practical new-type patent. Our newly developed super silent generator set have got certification of invention patent, and we are the only factory which could produce it. Our company have strong technical force, and perfect after-sales service system. Our products have been sold to many main cities in China, and all over the world including North America, European, South America, Southeast Asia, Middle East, Africa, etc.
"Widely making friends with universal heart, positively returning society with responsible mind", this is the aim of Changzhou Hi-earns Mechanical & Electrical Co., Ltd. In the fierce competition environment, we all Hi-earns staff shoulder to shoulder, insist the faith of "surpassing ourself continuously, developing innovation constantly", and continuously strive for being the first brand of domestic and overseas in mechanical & electrical field, this shows Hi-earns unique enterprise charm and grace, which means "sincerity, diligence, cooperation, devotion". We will continue to build enterprise brand sincerely, gain customers' trust with quality, stand on domestic and overseas market with good price, open the future of Hi-earns with strong ability.
