Plate-Type Fresh Water Generator/Seawater Desalination Plant
Type: FWG-5/FWG-10/FWG-20/FWG-30/FWG-40
Capacity: From 5t/d to 50t/d
Main features of plate type fresh water generator:
--wide range of production capacity(1~50D/T)
--Compact design for easy installation
--Standard parts for convenient replacement by crews
---Highly compatible to variety heating sources:
Steam heating block, hot water, thermal oil heating block
--High quality titanic plate, 316LSS&Al-Bronze for other component.
Sea water supply pump is only loose part which will be installed independently in proper position.
Control cabinet with embedded salinity meter directly fitted on the body of the unit and the cabinet also can be arranged separately in where convenient for operation.
China HANGYU Industry Co., Ltd is a main Supplier of Fresh Water Generator. RO Seawater Desalination Plant, RO Plant, Sewage Treatment Plant and Sterilizer, 15ppm Bilge Separator.
Please do not hesitate to contact us if you are interested in Fresh Water Generator or RO Plant. Thanks
| Mode(T/D) |
FWG-5 |
FWG-10 |
FWG-16 |
FWG-20 |
FWG-30 |
FWG-50 |
capacity |
5 |
10 |
16 |
20 |
30 |
50 |
Length(mm) |
770 |
970 |
970 |
1160 |
1400 |
1400 |
Width(mm) |
600 |
870 |
1150 |
1150 |
1250 |
1450 |
Height(m m) |
960 |
1150 |
1150 |
1415 |
1550 |
1550 |
Dry weight(kg) |
300 |
650 |
900 |
1150 |
1350 |
1450 |
Operation weight(kg) |
350 |
700 |
950 |
1250 |
1450 |
1600 |
