Guy wire tower
Height of pole: 12 m
Thickness: 7mm
Tower diameter: 273(mm)
Flange: 320*320*16 (mm)
Material: Q235 Steel pipe
Surface treatment: Painting against decaying
Generator
Blades diameter: 8.0(M)
Rated rotor speed: 200(r/m)
Rated speed: 8(m/s)
Rated power: 10KW
Max power: 20KW
Output voltage: 220V
Start up wind speed: 3(m/s)
Work speed: 3-30(m/s)
Security wind speed: 50(m/s)
Generator shell material: Pressure cast iron
Blades
Material of blades: FRP Lay-up by hand
Number of blades: 3PCS
Diameter of blades: 8.0M
Dome
Material of dome: FRP Lay-up by hand
Number of dome: 1PCS
Wind & solar hybrid controller
Rated Wind Input Power: 10kW
Rated Solar Power: 3kW
Rated Battery Voltage: 220V
Max Wind Input Current: 70A
Max Wind Input Power: 15KW
Unload Voltage: 252V
Unload Current: 0-25A Adjustable
Control Method: PWM
Display Method: LCD
Display Parameter: Battery voltage, wind voltage, PV voltage, wind current, PV current, wind power, PV power
Operation Ambient Temperature and Humidity: -20~+55/35~85%RH ( no condensing)
Protection Type:
Solar panel reverse-charge protection\Solar panel reverse-connect protection\Battery overcharge protection\Battery over discharge protection\Battery reverse-connect protection\Lightning Protection\wind turbine automatic brake and Manual brake protection\Wind turbine current-limited.
Inverter
Rated Output Capacity: 10kw
Rated Battery Voltage: 216VDC
Over Voltage Point: 306VDC
Over Voltage Recovery Point: 297VDC
Under Voltage Point: 189VDC
Under Voltage Recovery Point: 216VDC
No Load Loss: 0.4A
Output Waveform: Pure Sine Wave
Display Method: LCD
Display Parameter: Battery Voltage, Output Voltage, State Parameter
Cooling Method: Fan
Rated Output Voltage: 110/120/220/230/240 VAC
Total Harmonic Distortion: ≤ 4%
Output Frequency: 50/60 Hz± 0.05Hz
Dynamic Response: 5%
Overload Ability: 120% one minute, 150% 10 seconds
Inverting Efficiency: Max. 90%
Noise(1m): ≤ 40dB
Dielectric Strength: 1500VAC, one minute
Protection Type:
Battery over voltage protection\Battery under voltage protection\Battery
Reverse-connect protection\Output over load protection\Output short circuit
Protection\Over temperature protection
Operation Ambient Temperature: -20~50
Operation Altitude: ≤ 4000m
Operation Ambient Humidity: 0~90%, no condensing
Size(W× H× D)mm: 600× 890× 600
Weight(KG): 93
Tail Vane Board & Tail Vane Booms
Material: Q235 Steel plate
Surface treatment: Painting against decaying
Power |
10KW |
Blade diameter |
8.0m |
Rated rotor speed |
200r/min |
Rated speed |
10m/s |
Rated power |
10KW |
Max power |
20KW |
Output voltage |
220V |
Start up wind speed |
3m/s |
Work speed |
3-25m/s |
Security wind speed |
50m/s |
Height of tower |
12m |
Top quality except tower |
600kg |
Tower type |
guy wire tower |
Output controller system |
Controller & inverter |
System |
off-grid system |
Can spply power for |
Small Village, Referigerator, Washing Machine, Water Pump, TV, Lighting, Electric fan, Charge |
Qingdao Hengfeng Wind Power Generator Co., Ltd is one of the leading wind turbine manufacturer in China. Company start at 2004, Workshop covers more than 5000 square meters. It is about 1 hour by car to Qingdao Airport. And 30 minutes to Qingdao port. The traffic is very convenient.
Our company mainly produces 150 watts to 100 kilowatts of small and medium horizontal axis, vertical axis wind turbines, wind and solar power supply system, widely used in off-grid and on-grid power generation system. Produced in strict accordance with the ISO9001 international standard production system management, we have standard production line and automated packaging line, strict product testing system, advanced test equipment, to ensure provide customers the highest quality products and services; All products have achieved CE certification. Hengfeng has unrivalled experience and has built up a global reputation for their robust and reliable performance.
Our products has been export to more than 60 countries, for example, Europe, Middle East, Southeast Asia, Australia etc; Widely applied for island, military, maritime monitor, home use, commercial business and remote area etc, we have integrated design, production, sale and after-sale service. If you are thinking about reducing your domestic energy bills or providing a multi-site energy solution for your business, HENGFENG can help achieve your renewable energy aspirations. We make sure that your wind turbine choice will work productively for you and deliver all-round environmental benefits.
