About Us
Company founded in 1994, specialized in manufacturing wind turbines, the main products are 200W, 300W, 600W, 1KW, 2KW, 3KW, 5KW, 10KW, 20KW, 30KW, 50KW wind turbines and small solar panels, products are exported to the United States, Germany, Britain, France, Pakistan, Indonesia, Mongolia, has a customers high praise.
Product quality are reliable, the company developing on "technology to survive, quality to develop " and has passed CE, ISO9001 international quality certifications, from the technical design, product manufacturing, product inspection, etc. Have been used to maintain a complete management system.
2)Product introduction
FD8.0-10KW
Type of generator: Permanent magnet wind generator
Blade diameter: 8.0m
Blade materia: Fiber glass reinforcedl
Rated wind speed: 10m/s
Rated output power: 10000w
Max power: 15000w
Output Voltage: 380v
Startup wind speed: 3m/s
Job wind speed: 3-25m/s
Security wind speed: 40m/s
Tower type: 219mm219mm pull wire tubular tower
Tower high: 12m
Top section weight: 600kgs
Output controller system: Controller &wine wave inverter dogvane & anemoscope
Service life: 20 years
Can supply power for: Small village, air conditioner, small gas station, tollgate, refrigerator, washing machine, water pump, electric cooker, color TV, lighting, electric fan and chargin
Power |
200W |
300W |
600W |
1000W |
2000W |
3KW |
5KW |
10KW |
20kw |
30kw |
50kw |
Pictures |
Bitmap |
Bitmap |
Bitmap Bitmap |
Bitmap |
Bitmap |
Bitmap Bitmap |
Bitmap |
Bitmap Bitmap
|
|
FOB QINGDAO(USD) |
279 |
353 |
500 |
735 |
1118 |
2500 |
4118 |
10294 |
18676 |
25000 |
67647 |
Battery price (USD) |
132 |
132 |
176 |
353 |
529 |
1059 |
1191 |
2647 |
3088 |
6176 |
12353 |
Blade diameter (m) |
2 |
2 |
2.8 |
3 |
4 |
5 |
6 |
8 |
11 |
12.5 |
18 |
Rated Rotated speed(r/m) |
400 |
400 |
400 |
400 |
400 |
220 |
220 |
160 |
120 |
100 |
60 |
Rated wind speed (m/s) |
8 |
8 |
8 |
8 |
8 |
9 |
9 |
10 |
10 |
10 |
10 |
Rated power(w) |
200 |
300 |
600 |
1000 |
2000 |
3000 |
5000 |
10000 |
20000 |
30000 |
50000 |
Max power(w) |
350 |
450 |
750 |
1500 |
3000 |
4500 |
7000 |
15000 |
25000 |
35000 |
55000 |
Output voltage(v) |
24 |
24 |
24 |
48 |
96 |
192 |
220 |
380 |
380 |
380 |
380 |
Start up wind speed(m/s) |
3 |
3 |
3 |
3 |
3 |
3 |
3 |
3 |
3 |
3.5 |
3.5 |
Operating wind speed(m/s) |
3-25 |
3-25 |
3-25 |
3-25 |
3-25 |
3-25 |
3-25 |
3-25 |
3-25 |
3-25 |
3-25 |
Security wind speed(m/s) |
40 |
40 |
40 |
40 |
40 |
40 |
40 |
40 |
40 |
40 |
40 |
Height of tower (m) |
6 |
6 |
6 |
6 |
6 |
8 |
9 |
12 |
15 |
18 |
18 |
Weight of top section (kg) |
27 |
30 |
60 |
83 |
95 |
110 |
120 |
600 |
800 |
1130 |
2050 |
controller Parameter |
24V 40A |
24V 40A |
24V 40A |
48V 60A |
96V 60A |
220v 60A |
220v 60A |
380v 120A |
380v 120A |
380v 120A |
380v 120A |
Inverter Parameter |
DC24V →user’s local voltage & frequecy |
DC24V →user’s local voltage & frequecy |
DC24V→user’s local voltage & frequecy |
DC48V→user’s local voltage & freque |
DC96V→user’s local voltage & freque |
DC220V→user’s local voltage & freque |
DC220V→user’s local voltage & freque |
DC380V→user’s local voltage & freque |
DC380V→user’s local voltage & freque |
DC380V→user’s local voltage & freque |
DC380V→user’s local voltage & freque |
tower pole type(mm) |
60*3 |
60*3 |
75*4 |
75*4 |
89*4 |
133*5 |
159*5 |
219*6 |
377*6 |
426*8 |
free stand tower 18m |
20container(sets) |
120 |
96 |
72 |
60 |
48 |
20 |
15 |
|
|
|
|
40container(sets) |
240 |
192 |
144 |
112 |
96 |
38 |
26 |
10 |
9 |
5 |
4 |
Capacity and quantity of battery(reference) |
12V100AH 2pcs |
12V100AH 2pcs |
12V150AH 2pcs |
12V150AH 4pcs |
12V100AH 8pcs |
12V100AH 16pcs |
12V100AH 18pcs |
12V150AH 30pcs |
12V200AH 30pcs |
12V200AH 60pcs |
12V200AH 120pcs |
can supply power for |
lighting,electric fan,charger |
tv,lighting,electric fan,charger |
ice box,washer,waterpump,tv,lighting,electric fan,charger |
ice box,washer,waterpump,tv,lighting,electric fan,charger |
ice box,washer,waterpump,tv,lighting,electric fan,charger |
ice box,washer,waterpump,tv,lighting,electric fan,charger,air condition |
ice box,washer,waterpump,tv,lighting,electric fan,charger,air condition |
ice box,washer,waterpump,tv,lighting,electric fan,charger,air condition,samll village |
ice box,washer,waterpump,tv,lighting,electric fan,charger,air condition,samll village |
ice box,washer,waterpump,tv,lighting,electric fan,charger,air condition,samll village |
ice box,washer,waterpump,tv,lighting,electric fan,charger,air condition,samll village |
We specialize in this field for several years, with the strength of wind turbines, with good quality and pretty competitive price. SHANDONG JIALI NEW ENERGY Co., Ltd founded in 1994, specialized in manufacturing wind turbines, the main products are 200W, 300W, 600W, 1KW, 2KW, 3KW, 5KW, 10KW, 20KW, 30KW, 50KW and 100KW wind turbines and small solar panels, wind solar hybrid systems. Products are exported to the United States, Germany, Britain, France, Pakistan, Indonesia, Mongolia, has a customers high praise.
