1. Easy install and operation
2. Long lifetime and quality guarantee
3. Beautiful appearance and low noise
4. More electricity
Item Parameter
Blades diameterm: 8
Blade material and quantity 3 PCS Strenghthened form in one piece made by hand
Rated powerw: 10000
Max powerw: 12000
Annual power generationkwh: 15000-45000
Rated rotor speedr/min): 160
Start up wind speedm/s: 3
Working wind speedm/s: 4-25
Rated wind speedm/s: 11
Security wind speed m/s): 50
Working Voltagev: AC260
Batteries Voltagev/CapacityAh: 360V200AH
Speedgoverning method Electromagnetic damping adjusting speed
Brake method Manual bradesecurity protection system
Generator Type Three phase and permanent magnet generator
Generator class of insulation F
Host weight
Guyed Tower Height/Weightkg
Free Stand Tower Height/Weightkg
Whole system package volumem3
Noise LeveldB) < 65
|
CAT-10KW Wind Generator Technical Parameter |
|
Item |
Parameter |
|
Blades diameter(m) |
8 |
|
Blade material and quantity |
3 Pcs Strengthened form in one piece made by hand |
|
Rated power(w) |
10000 |
|
Max power(w) |
12000 |
|
Annual power generation(kwh) |
15000-45000 |
|
Rated rotor speed(r/min) |
160 |
|
Start up wind speed(m/s) |
3 |
|
Working wind speed(m/s) |
4-25 |
|
Rated wind speed(m/s) |
11 |
|
Security wind speed (m/s) |
50 |
|
Working Voltage(v) |
AC260 |
|
Batteries Voltage(v)/Capacity(Ah) |
360V200AH |
|
Speedgoverning method |
Automatically yaw+Electromagnetic damping adjusting speed |
|
Brake method |
Manual and Automatic brade, security protection system |
|
Generator Type |
Three phase and permanent magnet generator |
|
Generator class of insulation |
F |
Zibo CAT Wind Generator Co., Ltd. is a National high-tech enterprise specialized in research, development, marketing and sales of renewable energy products especially for wind power. The main products including Small and Medium wind generators, inverter & controller for photovoltaic system &wind system, solar and wind hybrid generators, solar and wind hybrid street light, wind-diesel hybrid system, wind-solar-diesel hybrid system.
We provide project consulting, system design, technical support, and other services to the whole project process.
Company Located in Zibo City, China, Near 1 hour from Jinan airport, 3 hours from Qingdao port. Covering an area of 4000 square meters. CE certified, the company has a complete series of strict testing and quality guarantee methods for all of the products. The products has exported to numerous oversea markets: North America, UK, Ireland, India, Italy, France, etc; There is also a wide range of domestic application of these product on oil field, farmland, industry park, military camp, fishing farm and port warehouse as well.
As a leading specialist in wind generators, CAT is committed to research, development, Manufacturing and marketing of innovative and superb renewable energy products that meet and surpass international standards and customer demands worldwide. Customer uppermost, Quality, Service are always frist, CAT will provide products which is the most suitable for you.
