| Model | HDG7500 | HDG10000 |
| ENGINE | Type | Horizontal water-cooled 4-stroke diesel engine | Horizontal water-cooled 4-stroke diesel engine |
| Model | GFF140 NES | GFFRD 180N |
| Cylinders | 1 | 1 |
| Bore X stroke (mm) | 98 X98 | 102 X115 |
| Displacement (cc) | 739 | 903 |
| Maximum Output (ps/rpm) | 14/2400 | 18/2400 |
| Reted Output (ps/rpm) | 12.5/2400 | 16.5/2400 |
| Lubricating oil | SAE#40API CF | SAE#40API CF |
| Cooling system | Radiator | Radiator |
| Fuel | Light diesel oil(SAE#2-D) | Light diesel oil(SAE#2-D) |
| Fuel tank capacity (L) | 10 | 10 |
| GENERATOR | Type | Brushless condenser | Brushless condenser |
| Model | HE13M | HE13L |
| Max. Output (KVA) | 7.5 | 10.5 |
| Reted Output (KVA) | 7.0 | 10 |
| Speed (rpm) | 3000/3600 | 3000/3600 |
| Frequency (Hz) | 50/60 | 50/60 |
| Pole | 2 | 2 |
| Power factor | 1 | 1 |
| Phase | 1 Phase 2 Wire | 1 Phase 2 Wire |
| Voltage | 220-240 | 220-240 |
| DIMENSION AND WEIGHT | Width(mm) | 600 | 600 |
| Length(mm) | 1290 | 1290 |
| Height(mm) | 710 | 710 |
| Net weight(Dry) (kg) | 280 | 325 |
Model: HDG10000
Type: Horizontal water-cooled 4-stroke diesel engine
Model: GFFRD 180N
Cylinders: 1
Bore X stroke (mm): 102 X115
Displacement (cc): 903
Maximum Output (ps/rpm): 18/2400
Reted Output (ps/rpm): 16.5/2400
Lubricating oil: SAE#40API CF
Cooling system: Radiator
Fuel: Light diesel oil(SAE#2-D)
Fuel tank capacity (L): 10
Type: Brushless condenser
Model: HE13L
Max. Output (KVA): 10.5
Reted Output (KVA): 10
Speed (rpm): 3000/3600
Frequency (Hz): 50/60
Pole: 2
Power factor: 1
Phase: 1 Phase 2 Wire
Voltage: 220-240
Width(mm): 600
Length(mm): 1290
Height(mm): 710
Net weight(Dry) (kg): 325
Professional generator manufactrurer with R&D capacity
Reliable quality, reasonable price, desirable service
Tell us your demand, provide what you want
Contact us now, let's make a deal...
EMEAN LIGHT UP YOUR LIFE!
Fuzhou Emean Electric Machinery Co., Ltd. is one of the biggest enterprises, lies in "China Electrical Machinery and Appliances City"--Fuan. EMEAN is a private enterprise established in 2003, which is a comprehensive electrical machinery manufacturing company integrating product designs, production, marketing and service.
Rely on scientific and technological development, we continue to provide users high-tech products, which is our consistent pursuit. On the basis of absorbing the foreign advanced technology, we have already fetched in 10 lines advanced international machinery production. The main products manufactured by our company consist of more than 10 series, over 100 types, involving generators, diesel generating sets, gasoline generating sets and concrete cutter, of which all of our products have been passed the national attestation CCC, CE certificate, Nigeria Soncap and EPA certificate.
EMEAN is a young enterprise, but she owns the fresh and great-hearted blood, which make her more charmful. "Quality assurance, user first" is the agreement of EMEAN executives. Communicate with the domestic industry, scientific research institutions exchange and cooperation so as to improving the quality, such as: Design and production, commissioning and maintenance. Then occupy the market, and expand the scale of the company. We have been moving forward to a more prosperous achievement under the fierce competition.
Today, EMEAN staff pursue the guidelines--"aggressive, realistic, strict and unity" to blaze new trails. We make technology as the core, quality as life and users to God, dedicated to provide you with the highest & cost-effective products and meticulous after-sales service in order to shape a bright future.
