10KW-2000KW GAS GENERATOR specifications of 10-1000kw natural gas generator price:
Gas gen-set Model | 50HZ, 1500rpm,400/230V, 3P 4W | Rated Current (A) | Gas-Engine | Alternator |
Rated Power (kW/kVA) | Standby Power (kW/kVA) | Model | Type | Rated Power (kW) | Model | Rated Power (kW/kVA) |
HQ-10GF | 10/12.5 | 11/13.75 | 18 | HQ-2100DT | four stroke, water cooled, wet cylinder liner | 14 | XN164C | 10.8 |
HQ-20GF | 20/25 | 22/27.5 | 36 | HQ-4100DT | 23 | XN184EF | 20 |
HQ-30GF | 30/37.5 | 33/41.25 | 54 | HQ-4105DT | 38 | XN184H | 30 |
HQ-40GF | 40/50 | 44/55 | 72 | HQ-6105DT | 60 | XN224D | 40 |
HQ-50GF | 50/62.5 | 55/68.75 | 90 | HQ-6105DT | 60 | XN224E | 50 |
HQ-70GF | 70/87.5 | 77/96.25 | 126 | HQ-6135DT | 82 | XN224G | 70 |
HQ-90GF | 90/112.5 | 99/123.75 | 162 | HQ-6135ADT | 100 | XN274D | 90 |
HQ-120GF | 120/150 | 132/165 | 216 | HQ-6140ADT | 130 | XN274F | 120 |
HQ-160GF | 160/200 | 176/220 | 288 | HQ-12V135DT | 175 | XN274H | 160 |
HQ-200GF | 200/250 | 220/275 | 360 | HQ-12V138DT | 220 | XN4C | 200 |
HQ-400GF | 400/500 | 440/550 | 720 | HQ-12V190DT | 450 | 1FC | 400 |
HQ-500GF | 500/625 | 550/687.5 | 900 | HQ-12V190ZDT | 550 | 1FC | 500 |
HQ-700GF | 700/875 | 770/962.5 | 1260 | HQ-12V190ZLDT | 750 | 1FC | 700 |
HQ-800GF | 800/1000 | 880/1100 | 1440 | HQ-12V190ZLDT | 850 | 1FC | 800 |
HQ-1000GF | 1000/1250 | 1100/1375 | 1800 | HQ-12V192ZLT2 | 1100 | 1FC | 1000 |
1) Rated power from 10kW to 1000kW
2) power by famous and good quality gas engine and alternator
3) Longer life: natural gas engine has a life of over several years if it is properly
operated and maintained
4) Low operation cost: natural gas has a rich reserve with low cost and a high
rate of return
5) High profit: low operation cost, supply of electricity and thermal power at the
same time, low maintenance cost
6) Coupled with brushless alternators of Leroy Somer / Engga
7) Well performed control system, high quality monitor instrument, with sound
and light alarm devices, auto shutdown
8) Protection function: over-current, under-voltage, auto-regulate voltage,
reverse power
9) Monitor function: speed, water temperature, lube-oil temperature, lube-oil
pressure, exhaust temperature
10) Gas consumption: less than 0.33cbm/kWh
11) Supply connection: 3 phase, 4 lines
12) Rated voltage: 400V
13) Rated speed: 1,500rpm/1,800rpm
14) Rated frequency: 50Hz / 60Hz
15) Rated power factor: 0.8
16) Exciting way: brushless
17) Starting mode: 24V DC electric starting system
18) Cooling mode: closed-circuit cooling system
packing in wooden case
Huaquan Power is specialized in producing diesel generator set, diesel generator, generator set, diesel generating set, generating, generating set, generator diesel, power generator, gas generator, nautral gas generator, eletric generator, alternator, diesel engine etc. We have open frame generator, automatic generator, trailer generator, silent/soundproof diesel generator, water pump etc. And the brands include Cummins, Perkins, Deutz, Steyr, Isuzu, Ricardo, Yuchai, as well as famous brands of alternator, such as Stamford, Faraday, Leroy-somer, Qiji. Power ranges from 3kw to 1000kw
Huaquan Power Mchinery Co., Ltd, located in diesel engine manufacturing powerhouse-Weifang, the capital of kites.
Huaquan Power has more than 500 employees worldwide and it has four advanced production lines, sophisticated testing equipment, complete quality management system, and marketing all around the world in the past 10 years, such as Southeast Asia, the Middle East, Africa and other regions.
Huaquan Power ensures that providing the energy saving, environment protection, high quality and reliable diesel engine and generators, to ensure user satisfaction and rest assured! We sincerely look forward to your cooperation!
