| Total Coolant Capacity | 29L |
| Thermostat | 82-95ºC |
| Max Water Temperature | 104ºC |
| | | |
| SMARTGEN CONTROLLER |
| 6110 Controller | 6120 Controller |
| CHARACTERISTICS: |
| ·LCD DISPLAY | Starting up can accumulate Max.999999 times |
| Using microprocessor as a core, Symbol LCD with backlight | ·Control protection: Automatic crank/stop of diesel engine, load |
| Display, two languages display, key touch operation | Transfer(ATS control) and completely faults display protection |
| ·RS485 PORT | ·With ETS, idle control, pre-eat control, raises speed control |
| Have a RS485 port with Modus communication protocol | functions and all types of them are belong to relay output |
| ·Adapt to 3 phase- 4 wires, single phase-2 wires or | ·Parameters setting: Allow user to modify setting and store |
| 2 phase- 3 wires(120/240V),50/60Hz AC power system. | Them by inside internal FLASH memory, the parameters can |
| ·Measure and display 3 phase voltage, 3 phase current, | not be lost even with power off. All of parameters can be set |
| frequency, power,etc.parameter of mains and gens: | not only from the front panel, but by PC via SG72(an adaptor, |
| MAINS GENS | USB-LINK-RS485) module; or, through RS485 port via PC |
| Line voltage(Uab,Ubc,Uca) Line voltage(Uab,Ubc,Uca) | ·Most of temperature, pressure, oil level sensor can be directly |
| Phase voltage(Ua,Ub,Uc) Phase voltage(Ua,Ub,Uc) | Used, and also user can define sensor curve by themselves |
| Frequency Hz Frequency Hz | ·Multiple crank disconnection conditions can be selected. |
| | (Speed sensor, oil pressure, gens) |
| LOAD | ·Power supply range is wide(8~35) VDC, accommodating to |
| Power current(IA,IB,IC) Apparent power kVA | Different starting battery voltage environments |
| Active power Kw Power factors Cos | ·All parameters use digital modulation, abandoning analog |
| Inactive power kVar Accumulate total gens power kWh | Modulation using conventional electronic potentiometer, more |
| ·Mains have over voltage, under voltage, loss phase function | Reliability and stability |
| ;Gens have over voltage, under voltage, over frequency, under | ·Modular configuration design, Flame Retardant ABS plastic |
| frequency, over current function | Shell, inserted type connection terminals, flush type |
| ·Precision measure and display parameters about Engine, | installation, compact structure, easy installation |
| Temp. (WT), ºC/ºF both are display | |
| Oil pressure(OP) kPa/Psi/Bar all be display | |
| Fuel oil level(FL) %(unit) | |
| Speed(SPD) RPM(unit) | |
| Voltage of Battery(VB) V(unit) | |
| Voltage of chargert(VD) V(unit) | |
| Hour count(HC) can accumulate Max.999999 hours | |
