Weifang Soundproof, water-cooled diesel generator. Output range: 20kw(25kVA) up to 200kw(250kVA)
1. Alternator: Leroysomer, Stamford, Marathon or Chinese brand Brushless alternator for export
2. Daily used fuel base tank
3. Key start / Auto start
4. Sound-proof / weather-proof canopy is optional
5.230/400V AC, 50Hz / 60Hz, 0.8pF, three-phase and four wires alternating current output
Engine: Water-cooled, in-line, 4-stroke, Humit cylinder liner, direct injection
Control system: A) Automatic alarm system: The unit has the acousto-optics alarm system and arrestor for any situation as the start defeat, the water is over temperature, the oil pulls down, over speed, over toad and over current
Operation display: 1)Unit voltage, tri-phase load current and frequency display 2) Water temperature, oil pressure display 3)Fuel level, fuel temperature display 4) Audible and visual alarm lamps and buzzers
Starting system: DC alternator is used to start engine
Short circuit protection: MCCB air switch
Cooling system: Combined cooling water tank fitted to meet the requirement of radiation at embient temperature 40oC
Filter system: Oil, fuel and air filter.
ALTERNATOR |
Alternator Model |
LSA 44.2 VS45 |
Rated power (Kw/Kva) |
80/100 |
Voltage (V) |
400/230 |
Current (A) |
144 |
Frequency (Hz) |
50/60 |
Power factor cosφ |
0.8(lagging) |
Excitation mode |
Brushless self-excitation |
Phase/Connection |
3-phase 4-wire Y type connection |
Voltage regulation rated |
≤ ± 1% |
Voltage Regulation |
Automatic |
Insulation grade |
H |
ENGINE |
Engine model |
6BTA5.9-G2 |
Intaking method |
Turbocharged |
Bore x stroke (mm) |
102× 120 |
Displacement (L) |
5.9 |
Compression ratio |
17.5: 1 |
Rated power (Kw) |
110 |
Lube oil capacity (L) |
12.1 |
Fuel consumption rate(g/kW. h) |
≤ 210 |
Starting system |
24V Electric starter |
