Rated Power: 1000W
Wind wheel diameter: 2.0M/2.1
Weight: 150KG
Blade Material: Aluminum Alloy
The number of blade: 3
Minimum wind speed start: 1m/s
Minimum power wind speed: 2m/s
Minimum charge wind speed: 3m/s
Rated wind speed: 13m/s
Maximum cut off wind speed: 15m/s
Item | Horizontal axis (HAWT) | Vertical axis (EML) |
Start wind speed | High(3m/s) | Low(1m/s) |
Wind conditions required | Require stable wind direction | Any wind direction |
Encountered turbulence | Reduce the efficiency | Efficiency is not affected |
Power stability | Change by wind direction | Without any wind effect |
Noise | Large(45 decibels or more) | Low noisy(because there is no mechanical friction) |
Product shape | Normal | Beautiful |
Installation height | High(need to avoid the terrain turbulence) | Low(not afraid of turbulence) |
Installation location | Just in open area like suburb | Any location |
Generator material | Plastic or composite | metal |
Structure strength | Poor (easy to broken) | High(high strengthen ) |
Resistance of wind speed | Poor(about 40 m/s) | High(about 65 m/s) |
Safety in utilization | poor | high |
weight | about 20KG | about 38KG |
Resistant to wind speed limit: 60m/s
The type of Generator: Three-phase AC maglev wind turbine
Controller output voltage: 24V
Controller output current: <50AMP
Controller brake system: Over speed automatic Three-phase short-circuit braking Normal operating temperature: -30~50
Willgain Power Industry Co., Limited is specialized in manufacturing and supplying wind turbine and generatering system since 2008. We mainly supply horizontal/vertical axis wind turbine from 300W-500kw, horizontal/vertical permanent magnet generator from 300W-1000kw with various speed based on customer's requirements and Francis/Kaplan type hydro turbine system below and over 50kw.
Our partner manufacturers are committed to continuously improving our operations and meeting the needs of our customers through innovation and new product development. We work closely with them to optimize the performance and cost-effectiveness of their processes.
