1. Application:
It's suitable for all kinds of home appliance, office equipment, solar power system, and other equipments which use single phase power
2. Features:
1. Pure sine wave output, available for sensitive load 4-step progressive charging, 7 battery type selector
2. Fast and powerful charger with 30A and 70A Accept generator' s energy output High power factor
3. Automatically transfer between battery and line modes
4. Microprocessor control guarantees high reliability Bypass without battery connected Remote control function
3. Protection against:
Over load
Over temperature
Over charging
Low battery Reverse connection(optional by hard connector) blackouts
Over&low voltage and current
4. Tech Parameters:
Model No.: 10001(2) 20001(2, 4) 30001(2, 4) 40002(4) 50002(4) 60002(4)
Nominal Power 1000W 2000W 3000W 4000W 5000W 6000W
AC Input:
Phase & waveform Single phase & sinewave
Voltage: 120VAC/230VAC
Acceptable Voltage: 194-243VAC\164-243VAC(wide mode)
Line Low Transfer: 85V± 4%/184(154 wide mode± 4%)
Line Low Return: 95V± 4%/194(164 wide mode± 4%)
Line high Transfer: 135V± 4%/253± 4%
Line high Return: 127V± 4%/243± 4%
Frequency: 50Hz or 60Hz (auto sensing)
Line Low Transfer: 47Hz for 50Hz, 57Hz for 60Hz
Line high Transfer: 55Hz for 50Hz, 65Hz for 60Hz
Output:
Phase & waveform Single phase & sinewave(bypass mode sync to input)
Voltage: 230VAC(bypass mode sync to input)
Voltage Regulation ± 10%RMS(bypass mode sync to input)
Frequency 50Hz± 0.3Hz(bypass mode sync to input)
Crest Power: 3 times of ratings
Short Circuit Protection: Yes, shutdown after 10 minutes
Power Factor: 0.9-1.0
DC Input:
Battery Voltage: 12V/24V 12V/24V/48V 24V/48V
Minimum Start Voltage: 10V for 12V, 20V for 24V, 40V for 48V
Low Battery Alarm: 10.5V for 12V, 21V for 24V, 42V for 48V
Low Battery Transfer: 10V for 12V, 20V for 24V, 40V for 48V
High Voltage Alarm: 16V for 12V, 32V for 24V, 64V for 48V
Max Charging Current: 70A\35A
Over Charge Voltage 15.7V for 12V, 31.4V for 24V, 62.8V for 48V
Transfer Efficiency:
Line Mode > 95%
Battery Mode: > 88%
Power saver: Available when the load is less than 25 Watts
Indicators:
7-LED Display "From the right to the left, LED1 line mode (green lighting), LED2 inverter mode
(green lighting), LED3 charging mode(yellow lighting), LED4 Fully charged
(green lighting, LED5 over heat shutdown(red lighting), LED6 Overloaded
Shutdown(red lighting), LED7 Saving Mode(green lighting) "
3-LED Display Charging Mode(green lighting), inverter mode(green lighting), Alarm(red lighting)
Switch selector "Saving Mode is on/off when push the switch forwards/backwards, keeping it horisontal is
Turning the inverter off. "
Audible Alarm: Sounding when the heatsink' s tem is over 105C and shutdown after 30 seconds.
Protections: Low battery, over charging, over temp, over load
Communications: RS-232/USB(custom-made)
Enviromental
Operating Environment: 0-40C, 0-90%RH(non-condensing)
Audible Noise: < 60dB
Physical
Net Weight(KG): 18 20 22 35 38 40
Dimension, D X W X H(mm): 218X179X442 218X179X598
