GENSET WORKING CONDITION:
GENSET WORKING CONDITION: |
|
ACCEPTABLE WORKING CONDITIONS: |
|
Ambient temperature : | -40°C~+45°C |
(antifreeze or hot water needed for below -20°C) |
|
Relative humidity: | <90%(20°C) |
Altitude: | ≤1000m |
NORMAL WORKING CONDITIONS: |
|
Genset can run at rated power on the conditions: |
|
Atmospheric Pressure: | 100kPa |
Ambient Temp: | 20°C |
Relative Humidity | 30%. |
APPLIED GAS: | Natural Gas, Biogas, Marsh gas, LPG, Coal-bed Gas |
Acceptable gas pipeline pressure: | 0.8~450kPa |
Engine inlet pressure: | 0.8~5.0kPa (80~500mmH2O) |
CH4 content: | for natural gas ≥85%; for biogas≥50% |
Sulphur content: | ≤400ppm |
Gas heat value: | ≥5500kcal/Nm3 (23MJ/Nm3 ) |
Alternator Features:
1. World famous brand AC alternator: Leateck, Stamford, Marathon,
2. Brushless, 4 poles, rotation magnet
3. IP21-23(NEMA1) enclose is standard for all industrial alternators
4. H class insulation system
5. AVR self-regulated, voltage regulation rate: ≤±1%
6. Simple installation and maintenance with easy access to terminals, rotating diodes and coupling bolts
7. Wide range of flange adaptors and single bearing disc coupling
8. Radio interference restraining accords with the stipulation of VDE0875-N and ISO8528
9. Moisture proof, sand-proof, dustproof, salt-proof and vibration-proof
Auto start control system:
Brand:Smartgen 6110 or Smartgen 6120(with ATS) optional. Customers can also select other brand such as HGM6310, HGM6320, DSE3110, DSE5110, DSE7110 and DSE7210 etc.
(1)Widely used in all types of generator automatic control system for compact structure,advanced circuits,simple connections and high reliability.
(2)LCD display,automatic control, Chinese and English display interface. Can be adjust from front panel, or use the PC through programming interface, also can use a PC via RSR485 interface and monitoring.
(3) Function:high water temperature, low oil pressure, low speed and over load protection,etc.
Features:
Reliable Quality:
Rich Experience, advanced technology and good selection on all parts etc. have made our gas generator sets to be more reliable and durable.
Longer Life:
Good quality and regular maintenance will make our gas generator sets to keep a longer life. Usually the life will be about 5-10 years for small power; about 10-15 years for large power.
Competitive Price:
We would try our best to offer every customer a reasonable and competitive price based on equality and mutual benefit.
Best Service:
We have deeply known the importance of pre-sale service, after-sale service etc. for a long-term development and would be responsible for every product we sell.
High return rate of investment:
Most suitable customized design and solution, more competitive price, lower fuel consumption, lower maintenance cost and longer life etc. will make you to earn a high return rate of investment.
Warmly welcome to our factory for visit:
1.From Guangzhou Baiyun International airport to Oripo:
a.It takes about 1 hour by car/taxi,it is about 58 kilometer;
b.Or take the subway from JiChangNan station to HanXiChangLong Station(you need to transfer at the TiYuXiLu station to PanYu direction), then take a taxi to Oripo, it will take about 1.5 hour.
2.From Canton fair complex to Oripo:
a. It takes about 30 minutes by car / taxi, it is about 32 kilometer;
b. Take the subway from XinGangDong Station / PaZhou station to HanXiChangLong Station, then take a taxi to Oripo, It will take about 1 hour.
Oripo Established in 1998, Oripo Power Engineering Co., Ltd is professional leading manufacturer, suppliers, exporter and authorized dealers of diesel gensets. With over 20, 000 square meters and a staff nearly 200, the headqauter is loacted in Foshan city, adjacent to Guangzhou which is the trade center of Guandong province. We offering power genset, industrial genset, silent genset, weather proof genset, Cummins genset, Perkins genset, Yuchai genset, Shanghai Dongfeng genset, Deutz genset, Weichai electric genset, China domestic genset, silent diesel generator, portable power generator, trailer diesel generator and electric power generator.
Currently, Oripo cooperated with multinational companies formed a strategic partnership. Import CUMMINS, PERKINS series generator sets, and purchase engine from with Cummins, SDEC, Yuchai, LOVOL, Deutz, alternater with STAMFORD, MARATHON, LEADTECH and other international or domestic famous brand. Establish a long-term friendly cooperation relations with the branded engine and alternator company, authorized to be the OEM partner, In 2009, Oripoe authorized by Cummins, Shanghai Dongfeng and Yuchai to provide OEM service. As professional qualified manufacturer provide OEM genset, spare parts, after sale service, in order to better serve customers and laid a solid foundation.
During the last ten odd years, Oripo has been dedicated to pursuing professional production, thus prevailing in the market with its superior quality, cutting-edge technology and tailor-made services. Moreover, with an endeavor to expand our business operations, we adhere to ethical business practices, transparent business dealings and work to attain the confidence and trust of our clients.
