Home Generator Products 100-600kVA Biogas Power Plant Generator Set

100-600kVA Biogas Power Plant Generator Set

100-600kVA Biogas Power Plant Generator Set
Price: US $ 23900/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 1/Piece
Pay Type: L/C,T/T
100-600KVA biogas  power  plant  generator set



Specifications



1.Supply power from 10KW to 1000KW
2. Advanced Control Panel
3. Water-cooled engine
4. Service OEM Offer




Product Description

Biogas engine generator general description:

This type of generator is choose gas as power. Gas will be burned directly inside of engine's cylinders, then give machinery force to alternator to produce electricity power. There are mainly 3 parts on one generator set: gas engine,alternator and radiator. The generated power can be connect to national grid, or for daily use and industrial use.



Biogas engine generator simple description:

Manufacturer supply

Max power supply range:10-1000kw
Continuous power supply range: 8-880kw
Standard component and assembly
Multi-option of control panel
With CE and ISO certificate



Biogas generator parameter:

Model Number (Engine Type)

LHBG10-1000

Brand Name

LVHUAN

Prime Power/Standby Power

10-1000 KW

Gas mixing type

outside of cylinder

Rated Speed

1000/1500r/min

Rated Frequency

50/60Hz

Rated Voltage

400V/230V

Phase

AC 3-Phase, 4 wire

Voltage Stability

≤±2%

Voltage transient

≤±10%

Voltage Stable time

≤1

Heat consumption

≤9.8mj/kw.h

Lubricant consumption

≤1.0g/kw.h

Engine Capacity

1.81-71.45 L

Cylinder Number

2-16

Cylinder Bore

100-190mm

Stroke

115-210mm

Starting System

DC 24V eclectic motor

Cooling method

water cooler

Lubricant method

Pressure and splash

Isolation class

H

Protection

IP23

Alternator

ENGGA

Power Factor

0.8 lagging

Exciting method

brushless

Color

your choice

Certificates

ISO 9001:2008,CE

Warranty

12months/ 1500 running hours

Type

Open

Control System

Automatic alarm system

(Single set power supply range: 10 - 600 kw, ≥2 sets parallel together to form large power, Eg. 600kw*2 sets = 1200 kw)

Machine supply details:
Ignition system:We adopt ignition system of magneto which produced by American ALTRONIC company,including:magneto,high-tension coil,sparking plug.
Starting system: DC24V electric motor,12v190 adopt ST710 of direct-current.
Pressure charging system:Pulse Mixed-flow  supercharger, compression ration is  1:8,meet engine's  requirement   for gas-flow rate.
Speed regulating system: EGS gas controller of American WOODWARD Company.

Full automatic system for optional: ATS for automatic switch form national grid power to generated power, double direction.

Low voltage cables between generator set and control room: available if needed.



Features of our biogas generator:

1.Pure copper water tank for best cooling effect

2.Famous component brand to ensure overall quality, Eg. Siemens,Standard, Stamford.

3.Expansion fitting combined with shrinking fitting give high tightness to the system.

4.Safety guarantee form electromagnetic valve as well as back-fire relief valve

5.Residual heat CHP recycle system available for choice.


biogas generator photo:




   contact details

      Amy Yao

Shandong Lvhuan Power Equipment Co., Ltd.
Add: Hi-tech Development Zone, Jinan ,Shandong, China
Mobile:+86 18605316485
Office number: +86 531 88888499
Prod Model: LHBG100
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Controller: Comap, Deepsea
Lube Oil: Total Gas Engine Oil 15W-40
Cooling Mode: Closed or Open Type Water Cooling
Color: Yellow or Custom Colors
Alternator: Siemens: Brushless, Self-Excited, with AVR, Insula
Ignition System: Altronic
Lubrication Mode: Pressure and Splash
Export Markets: Global
Gas Source: Biogas
Power: 100kw
Shandong Lvhuan Power Equipment Co., Ltd. is a manufacturer which specially produces internal-combustion gas engine generator sets and gas engines, with registered capital of more than RMB10 million, annual turnover of RMB100 million, over 200 staff, beautiful scenery and convenient transportation. Our factory mainly specializes in the design, research, production, sale, installation and technical service of gas generator sets and diesel generator sets. Our company has strong specialty, powerful technical force, a complete production plant, advanced processing technology, mature inspection method and a strict test system.

Our products include 105, 135 and 190 series base engines. The output power ranges from 10kw to 500kw. The gensets can be used for biogas, natural gas, oil associated gas, coal mine gas and mash gas produced by burying rubbish and sewage disposal.

We manage our company by ISO9001 system strictly. Gas engines and alternators are environment-friendly products.

Our philosophy is "Only pay attention to supplying stronger power to you". More importantly, combining with our continuous technological innovation and hard work, we believe that you will choose our company and keep a long-term business relationship with us!
