The motor speed, voltage, power can be customized according to the requirements, but its better to be no more than 15, 000 speed. The motor can be made as wind cooling or water cooling, AC or DC. The front cover of the motor could have flange front edge, the size and the output shaft can also be customized.
power | Voltage | speed | Rated torque | Peak torque | Peak power | current | Current peak | Efficiency | weight |
1.5kw | 220V | 18000 | 0.79 | 1.5 | 2.2 | 4.3 | 8 | 92.5% | 6kg |
2 kw | 220V | 20000 | 0.95 | 2 | 3 | 5.7 | 10 | 92.5% | 7kg |
3 kw | 220V | 30000 | 0.95 | 2 | 4.5 | 8.6 | 16 | 92.5% | 8kg |
Xinda Green Energy Co., Limited is specialized in handling the business of vertical and horizontal wind turbine generator, various kind of permanent magnet generator(0.05-3000kw), speed from 20rpm-20000rpm, both vertical and horizontal, small hydro turbine system(low head and higher head), wind solar hybrid system, high efficiency high seepd permanent magnet motor, street lamp and so on
Our partner manufacturers are committed to continuously improving our operations and meeting the needs of our customers through innovation and new product development. We work closely with them to optimize the performance and cost-effectiveness of their processes.
