Generator:
Frequency: 50/60
Rated output (kW): 1.0/1.1
Max output (kW): 1.1/1.2
Phase number: Single phase
Power factor (cosφ ): 1.0
Rated voltage (V): 110, 120, 220, 230, 240
Engine
Model: GE154
Max. Output (HP): 2.8
Displacement (CC): 87
Noise level (7m): 60dB
Starting system: Recoil
Type: Single-cylinder, 4-stroke, air-cooled, OHV
Ignition system: T. C. I
Fuel tank capacity (L): 6.0
Lube oil capacity (L): 0.6
Package
Dimension (mm): 460*380*390 with frame
N. W/G. W (kg): 19/20 20/21 21/22
Qty/20" FCL (sets): 750 / 720 with frame
Features:
Single-cylinder, 4stroke, air-cooled gasoline engine
OHV design ensures the lower fuel consumption
Overload Protection for safe running
With low oil alert
Brushless alternator
Optional:
12V DC 8.3A output
|
TECHNICAL DATA |
|
|
|
MODEL |
GG1000 |
|
Generator |
Frequency |
50 |
60 |
|
Rated output (kW) |
1.0 |
1.1 |
|
Max output (kW) |
1.1 |
1.2 |
|
Phase number |
Single phase |
|
Power factor (cosφ ) |
1.0 |
|
Rated voltage (V) |
110, 120, 220, 230, 240 |
|
Engine |
Model |
GE154 |
|
Max. output (HP) |
2.8 |
|
Displacement (cc) |
87 |
|
Noise level (7m) |
60dB |
|
Starting system |
Recoil |
|
Type |
Single-cylinder, 4-stroke, air-cooled, OHV |
|
Ignition system |
T. C. I |
|
Fuel tank capacity (L) |
6.0 |
|
Lube oil capacity (L) |
0.6 |
|
Package |
Dimension (mm) |
460× 380× 390 |
|
N. W/G. W (kg) |
28/29 |
|
Qty/20" FCL (sets) |
420 |
Belyton power Ltd. is a manufactuer, which professionally produces a series of gasoline and diesel generators and water pump and gas and LPG generator.
Our water-cooled diesel generator from 10kw to 800kw has 20years experience.
The head office is located in Fuan (Electric Motor and Appliance Area) - the economic center in the east of Fujian Province of China.
The products are well received in more than one hundred countries and regions, such as the Middle East, Africa, Southeast Asia, Europe and South America.
We guaranteed products at a competitive price and high quality. At present, our products have a very good sale in domestic and overseas market. We wish to cooperate with you to create a bright future and mutual benefit. Much appreciation for your prompt attention in advance, we are eager to look forward to hearing from you soon.
